miniBOOSTERs are oscillating pressure intensifiers that can be mounted on low-pressure hydraulic systems. The miniBOOSTER will automatically intensify system pressure giving a higher outlet pressure. The miniBOOSTERs come in a vast range of models, each representing different functions for different environments.
Product range from miniBOOSTER Hydraulics A/S
We have a comprehensive range of hydraulic pressure intensifiers that cover 13 intensification factors up to 5,000 bar and flows up to 400 l/min, using almost any media including tap water. The range covers flanged versions, tube versions and cartridge versions and includes standard blocks with built-in valves option that dramatically reduces the need for space and piping.
The miniBOOSTER product range covers your needs. View the entire miniBOOSTER product range in table format, containing data such as flow, pressure, weight and material.
BOOSTERS
| P-outlet bar | Intensified outlet Q l/min | P-inlet bar | Inlet Q l/min | Connection | Weight, kg | Factor, i | Steel | Stainless steel |
|---|---|---|---|---|---|---|---|---|
| 24 - 800 | 0.3 - 0.5 | 20 - 207 | 2.0 - 8.0 | · Tube · Flange | 0.7 | 1.2 - 7.5 | · HC1 | · HC1W |
| 24 - 800 | 0.3 - 2.5 | 20 - 207 | 2.0 - 15.0 | · Tube · Flange | 1.0 | 1.2 - 20.0 | · HC2 | · HC2W |
| 24 - 800 | 0.7 - 11.0 | 20 - 207 | 2.0 - 15.0 | · Tube · Flange | 3.8 | 1.2 - 20.0 | · HC2D · HC2D-D | · HC2DW |
| 80 - 1,380 | 1.5 - 5.0 | 20 - 207 | 2.0 - 14.0 | · Tube · Flange | 8.0 | 4.0 - 13.0 | · HC2DHW | |
| 24 - 500 | 0.3 - 2.5 | 20 - 207 | 2.0 - 15.0 | · Flange | 2.5 | 1.2 - 20.0 | · HC3 | |
| 26 - 800 | 1.5 - 7.0 | 20 - 207 | 2.0 - 35.0 | · Tube · Flange | 3.7 | 1.3 - 9.8 | · HC4 | · HC4W |
| 100 - 3,000 | 1.2 - 3.5 | 20 - 207 | 2.0 - 38.0 | · Tube · Flange | 4.0 | 5.1 - 17.3 | · HC4H | |
| 26 - 800 | 2.5 - 15.0 | 20 - 207 | 5.0 - 70.0 | · Tube · Flange | 9.5 | 1.3 - 8.2 | · HC6 | |
| 124 - 5,000 | 1.0 - 7.0 | 20 - 207 | 5.0 - 50.0 | · Tube · Flange | 11.0 | 6.2 - 25.0 | · HC6H | |
| 24 - 800 | 11.2 - 56.0 | 20 - 207 | 5.0 - 70.0 | · Tube · Flange | 20.0 | 1.2 - 8.2 | · HC6D · HC6D-D | · HC6DW |
| 80 - 1,380 | 3.0 - 12.5 | 20 - 207 | 5.0 - 50.0 | · Tube · Flange | 35.0 | 4.0 - 16.0 | · HC6DHW | |
| 100 - 2,000 | 0.3 - 1.6 | 20 - 207 | 2.0 - 14.0 | · Tube · Flange | 1.5 | 5.0 - 20.0 | · HC7 | · HC7W |
| 100 - 2,000 | 0.3 - 1.6 | 20 - 207 | 2.0 - 14.0 | · Tube · Flange | 4.5 | 5.0 - 20.0 | · HC8 | |
| 220 - 5,000 | 0.3 - 1.8 | 20 - 207 | 5.0 - 20.0 | · Tube · Flange | 9.9 | 8.2 - 25.0 | · HC9 |
BOOSTERS, DOUBLE ACTING
| P-outlet bar | Intensified outlet Q l/min | P-inlet bar | Inlet Q l/min | Connection | Weight, kg | Factor, i | Steel | Stainless steel |
|---|---|---|---|---|---|---|---|---|
| 24 - 800 | 0.3 - 2.5 | 20 - 207 | 2.0 - 15.0 | · Tube | 3.0 | 1.2 - 20.0 | · HC5 |
BOOSTERS, 2-MEDIA
| P-outlet bar | Intensified outlet Q l/min | P-inlet bar | Inlet Q l/min | Connection | Weight, kg | Factor, i | Steel | Stainless steel |
|---|---|---|---|---|---|---|---|---|
| 20 - 800 | 2.0 - 3.0 | 20 - 207 | 2.0 - 15.0 | · Tube · Flange | 4.2 | 1.2 - 12.0 | · HC2D2 | · HC2D2W |
| 80 - 1,380 | 0.6 - 1.6 | 20 - 207 | 2.0 - 8.0 | · Tube · Flange | 8.0 | 4.0 - 12.0 | · HC2D2HW | |
| 20 - 800 | 6.0 - 41.0 | 20 - 207 | 5.0 - 70.0 | · Tube · Flange | 24.0 | 1.0 - 10.1 | · HC6D2 | · HC6D2W |
| 20 - 1,380 | 2.0 - 5.6 | 20 - 207 | 5.0 - 30.0 | · Tube · Flange | 25.0 | 5.2 - 15.0 | · HC9D2 | · HC9D2W |
BOOSTERS, CARTRIDGE
| P-outlet bar | Intensified outlet Q l/min | P-inlet bar | Inlet Q l/min | Connection | Weight, kg | Factor, i | Steel | Stainless steel |
|---|---|---|---|---|---|---|---|---|
| 24 - 800 | 0.3 - 0.5 | 20 - 207 | 2.0 - 8.0 | · Cartridge | 0.7 | 1.2 - 7.5 | · HC1-9 | |
| 24 - 800 | 0.3 - 2.5 | 20 - 207 | 2.0 - 15.0 | · Cartridge | 1.0 | 1.2 - 20.0 | · HC2-9 | |
| 24 - 500 | 0.3 - 2.5 | 20 - 207 | 2.0 - 15.0 | · Cartridge | 2.5 | 1.2 - 20.0 | · HC3-9 | |
| 100 - 2,000 | 0.3 - 1.6 | 20 - 207 | 2.0 - 14.0 | · Cartridge | 1.5 | 5.0 - 20.0 | · HC7-9 |
